UP-9100
Ultra-high Flow Booster Pump

Ultra-high Flow Booster Pump

  • Ultra-high flow rate.
  • Low current flow, power saving.
  • 0~150 psi/100,000 cycles inlet water resistance.
  • 5~45°C stable low temperature running design.
  • Life time test: pass 1,000 hrs at 70 psi.
  • Minimum total head: >10m
  • CE certified.
  • This pump had been discontinued and replaced by the UP-9110 and UP-A2004T booster pump .

Specification

Voltage 24 VDC
Power Hertz 50 / 60 Hz
Rated Power 120 W
Suggest Inlet Pressure 20 PSI
Working Pressure 70 PSI
Working Flow ≧ 3.0 L / min
Operating Current ≦ 2.0 A
Max. Pressure (By Pass) 140 PSI
Dimensions 195x105x103(mm)
Weight 2.3(kg)
