UP-7000
Puricom UP-7000 High Flow Booster Pump

High Flow Booster Pump

  • High flow rate.
  • Quiet operation with low noise and no trembling.
  • 0~150 psi/100,000 cycles inlet water resistance.
  • 5~45°C stable low-temperature running design.
  • Life time test: pass 2,000 hrs at 70 psi.
  • CE certified.
  • This pump had been discontinued and replaced by the UP-7011 and UP-7011S booster pump.

Specification

Voltage 24 VDC
Power Hertz 50 / 60 Hz
Rated Power 24 W
Suggest Inlet Pressure 20 PSI (1.4 bar)
Working Pressure 70 PSI (4.8 bar)
Working Flow ≧ 550 mL / min
Operating Current ≦ 0.7 A
Max. Pressure (By Pass) 110 PSI (7.6 bar)
Dimensions 173 x 102 x 103 (mm)
Weight 2000 (g)
