High Flow Booster Pump

Quick connect design. Easy for installation.
Most compact pump with lighter weight.
0~150 psi/100,000 cycles inlet water resistance.
5~45°C stable low temperature running design.
Life time test: pass 1,000 hrs at 70 psi.
This pump had been discontinued and replaced by the UP-A1001P booster pump .

Specification

Voltage	24 VDC
Power Hertz	50 / 60 Hz
Rated Power	24 W
Suggest Inlet Pressure	20 PSI (1.4 bar)
Working Pressure	70 PSI (4.8 bar)
Working Flow	≧ 700 mL / min
Operating Current	≦ 1.2 A
Max. Pressure (By Pass)	110 PSI (7.6 bar)
Dimensions	157 x 60 x 60 (mm)
Weight	800 (g)
