UP-8000
Ultra-high Flow Booster Pump

Ultra-high Flow Booster Pump

  • Ultra-high flow rate.
  • Life time test: pass 1,000hrs at 70 psi.
  • 0~150psi/ 100,000 times inlet water resistance.
  • 5~45°C stable low temperature running design.
  • Minimum total head: >10m
  • CE certified.

  • UP-8000 24 VDC / 36 VDC / 48 VDC had been discontinued.


Specification

Voltage 24 VDC 36 VDC 48 VDC 110 VAC
Rated Power 60 W 72 W 96 W 96 W
Power Hertz 50 / 60 Hz
Suggest Inlet Pressure 20 PSI (1.4 bar)
Working Pressure 70 PSI (4.8 bar)
Max. Pressure (By Pass) 140 PSI (9.7 bar)
Dimensions 196 x 102 x 103 (mm)
Weight 2300 (g)
Remarks For 110 VAC type, the pump can be optional to add rectifier circuit control box. For 36 or 48 VDC type, there is adaptor included.
