UP-7011S
Puricom UP-7011S High Flow Booster Pump

High Flow Booster Pump

  • High flow rate, stable pressure, and long lifespan.
  • Self-priming design ensures stable water output without relying on water pressure.
  • Quick connect design.  Easy for installation.
  • The pressure-bearing components are made of high-strength plastic and metal.
  • Low noise, low vibration, high power DC motor configuration.
  • Water-contact components meet NSF and FDA food-grade requirements.
  • Applied to RO systems of 50-100 GPD.
  • CE certified.
  • Life time test: pass 2,000 hrs at 70 PSI.

Specification

Voltage 24 VDC
Self-priming height ≧2m
Interface method 1/4” top female quick connector
Rated Power 39 W
Inlet Pressure 0 PSI
Working Pressure 70 PSI (4.1 - 5.5 bar)
Working Flow ≧ 800mL / min
Operating Current ≦ 1.3 A
By Pass Pressure 116 - 145 PSI (8 - 10 bar)
Dimensions 157 x 70 x 68 (mm)
Weight 960 (g)
