OTM-0201
OTM-0201_water_softener

Water Softener

  • Simple structure, compact design brings convenient installation.
  • Its design is optimized for low water consumption and a reduced flow rate, making it an ideal choice for modern homes.
  • Provides a continuous flow of softened water with peak rates up to 2.5 m³/h.
  • Exclusive NSF-certified electronic control valve with reliable piston, seal, and spacer technology.
  • With an electronic controller to adjust all operating cycles.
  • Time saving quick connect fittings on bypass, drain, and brine lines.
  • Brine valve with safety float for extra overflow protection.
  • Ergonomically designed handle for easy mobility.


Specification

Model Name
OTM-0201
Regeneration Type
Down flow
Regeneration Mode
Meter immediate, meter delay, day override, vacation
Tank Size
10X35 (inch)
Resin Quantity
25 L
Salt Storage Capacity
52 kg
Distributor Pilot
OD 1.05
Product Dimension
D 528 X W 346 X H 1086 (mm)
Electrical Requirements
Input 110-120V / 220-240V AC50 / 60 Hz
Output 12V AC650 mA
Plumbing connections
3/4" or 1” fittings available
Operating pressure
0.21-0.86 MPa
Water temperature
1℃~39℃
Water supply
Tap Water
Performance (@ 96 g/L salt dosage)
Hardness Removal
1094 g
Salt Used-Per Regeneration
2.4 kg
Rated Service Flow
2.0 m3/h
Back Wash Flow Rate
9.0 L/M
Water Used Per Regeneration
112 L
